MANET MEWLink 900

MANET MEWLink 900

Introducing an RF module for the ISM Band (917 ~ 923.5MHz) that supports MANET.

MANET MEWLink 900 Features

MANET MEWLink 900 is an RF module for the ISM Band (917 ~ 923.5MHz) that supports MANET. With multi-hop based network formation and stable routing, it enables predictable communication operations in the field.

Build a predictable multi-hop MANET where transmission/response time can be estimated

MANET MEWLink repeatedly searches and establishes routes, and prevents signal transmission/reception loss throughout the entire communication process over an established path. As a result, transmission and response times become predictable, and a wireless network can be built where uncertainty is effectively removed—except for physical loss due to interference or environment.

Improve reliability by avoiding signal collisions during routing setup

MANET MEWLink applies an on-demand (reactive) approach that suppresses unnecessary traffic unrelated to actual communication. It can establish redundant routes without extra overhead, and fundamentally avoids real-time signal collisions during communication, improving reliability. This also enables a complete mesh network where all nodes can communicate with redundant paths.

Media Transmission & MANET Characteristics


In general MANET networks, the ability to avoid signal collisions during communication is not reflected in routing decisions, so minimum QoS to guarantee stable latency is not supported. However, MANET networks using MANET MEWLink can predict transmission/response time and avoid collisions, enabling media transmission such as voice in 1:1 communication.

Supports Full MANET Characteristics

  • No infrastructure
  • - no base station
  • - no backbone
  • No network operator
  • Multi-hop wireless communication
  • Mobility
  • - node mobility
  • - network mobility

AEG09T3R10 module
Model : AEG09T3R10

AEG09T3XX0 module
Model : AEG09T3XX0

Common Technical Specifications

FUNCTION ITEM SPECIFICATION
MobilityYes
Ad-hocYes
Multi-hopYes (Max. 7-hop)
Routing MethodOn-Demand-Driven / Reactive
TopologyCluster Tree / Mesh
Routing Time (unit : sec) (diversity, frame length=Typ. 5ms)≤ 93.0 (@240-node, 7-hop)
Routing Path 1:N broadcast / multi-castYes
Routing Path 1:1 unicastYes
Multi-path & Diversity2
QoS of Data Transmission 1:N broadcast / multi-castYes
QoS of Data Transmission 1:1 unicastYes
QoS of Media Transmission 1:N broadcast / multi-castNo
QoS of Media Transmission 1:1 unicastYes
Transmission Delay 2 × (Frame Length) + { (Number of Nodes) × (Frame Length) × (Number of Hops-1) } / { (Number of Hops) × (Frame Length) × 2 }
Network Operation 1:N broadcastHalf-duplex
Network Operation 1:1 unicastHalf-duplex
Number of Nodes≤ 240EA
Simultaneous Operation Channels1 (w/ diversity)
Media Access MethodTDMA / SYNC.
Frequency Operation Method FF (Fixed Frequency)Yes
Frequency Operation Method FH (Frequency Hopping)Yes, but not implemented

Model Technical Specifications

FUNCTION ITEM AEG09T3R10 AEG09T3XX0
Frame Length5msec5msec
Payload Size per Frame60-byte60-byte
Frequency(MHz) / Channels917 ~ 923.5 (ISM Band)917 ~ 923.5 (ISM Band)
Channel Spacing200KHz200KHz
PHY Level Data Rate200Kbps(@100Ksps)200Kbps(@100Ksps)
RF Output Power< 200mW< 25mW
RX Receiving Sensitivity-108 dBm-90 dBm
Modulation4GFSK4GFSK
Transmission Distance≤ 500m(@LOS)≤ 200m(@LOS)
Supply Voltage5.0V5.0V
Temperature-40°C ~ 85°C-40°C ~ 85°C
Power Consumption340mA(TX), 44mA(RX), 12mA(Idle)57mA(TX), 32mA(RX), 12mA(Idle)
Dimension25 x 28mm25 x 22mm

Pin description & Dimension

PIN DESCRIPTION (Model : AEG09T3R10)

Pin description

DIMENSIONS

Dimensions

Model & Part Numbers

Model Number Part Number Description Package

RF MEWLink 900		 AEG09T3R10 RF Module, 917~923MHz, 200mW SMT
AEG09T3XX0 RF Module, 917~923MHz, 25mW SMT
